RB-1590 - STEREO AMPLIFIER

The RB-1590 is at the top of its class as a 2 x 350 Watts stereo amplifier with dual toroidal transformers and special slit foil capacitors.

• 2 x 350 Watts of robust power
• Class AB amplifier design
• Massive power supply using Dual Toroidal Transformers
• High quality slit foil capacitors made in Britain
• Balanced XLR inputs

SPECIFICATIONS:

DIMENSIONS (W × H × D)
431 × 237 × 454mm
17" × 9.75" × 17.9"

FRONT PANEL HEIGHT
5U / 221mm (8.75")

POWER REQUIREMENTS
120V, 60Hz

POWER CONSUMPTION
800W

STANDBY POWER CONSUMPTION
0.5W

NET WEIGHT
38.1kg (84lbs.)

BTU RATING (4Ω, 1/8th power)
2100 BTU/h

CONTINUOUS POWER OUTPUT
350W/Ch (All channels driven, 8Ω)

TOTAL HARMONIC DISTORTION (THD)
(20Hz–20kHz) <0.03%

FREQUENCY RESPONSE
10Hz - 100kHz ±0.5dB

S/N RATIO (IHF "A" Weighted)
120dB

GAIN
RCA: 27.5dB
XLR: 23.5dB
